Hero Impulse Specifications

Hero Impulse specifications is one of many posts that detail information about Hero Impulse. I have put up the details as seen in the Owner’s Manual provided with the motorcycle. I did look at the Hero Moto Corp website, with the intention of just linking out to it, but it is incomplete and erratic. Moreover, given that they may phase this motorcycle out, it makes more sense to have it here.

Hero Impulse Specifications Owners Manual

Isn’t it great that the manual also has an orange motorcycle? And, the woman at the showroom left no space for doubt about who owned this.

Hero Impulse Specifications

Technical

Engine

TypeAir-cooled, 4- stroke single, cylinder OHC , Electric start
Displacement149.2 cc
 Power 9.7 KW (13.2 Ps)  at 7500rpm
 Torque13.40N-m @ 5000rpm
 Bore and Stroke 57.3 x 57.8mm
 Compression Ratio9.1:1
Spark Plug NGK-CPR 8 EA 9
 Spark Plug Gap0.8 to 0.9 mm
 Valve Clearance (Cold)IN: 0.08mm Ex: 0.12mm
 Idle Speed1400rpm +/- 100

Dimensions

Overall Length2100 mm
Overall Width 820 mm
Overall Height1160 mm
Wheelbase1360 mm
Ground Clearance245 mm

Weight

Kerb Weight134 kg

Various Fluid Capacities

Engine Oil1.1 litres (Dis-assembly)
0.90 litres (Draining)
Fuel Tank1.1 liters (Dis-assembly)
0.90 litres (Draining)
Fuel Reserve Capacity 11.1 litres (least)
Front Fork Oil (Dis-assembly)176cc
Hydraulic Brake FluidDOT 3 or DOT 4

Chassis and Suspension

Front SuspensionTelescopic Hydraulic Type
Rear SuspensionSwingarm with Mono Suspension with Nitrox
Caster26 degrees
Trail99 mm
Front Tyre Size90/90×19 – 52 P
Rear Tyre Size110/90×17 – 60 P
Front BrakeType – Disc
Diameter – 240mm
Rear BrakeType – Drum
Diameter – 110 mm

Transmission

Primary Reduction 3.3500 (67/20)
Final Reduction 2.9411 (50/17)
Gear Ratios1st3.0769 (40/13)
 2nd1.7895 (34/19)
 3rd1.3043 (30/23)
 4th1.0909 (24/22)
 5th0.9375 (30/32)

Electrical

Battery12v – 4Ah, MF Battery
Alternator140w
Starting SystemElectric Start and Kick Start
HEadlight (High/ Low)12v 35/35w Halogen bulb
Multi Reflector type clear lens unit
Tail/ Stop Light12v 0.5w/ 4.1w L.E.D Lamps
Turn Signal Light12v 10w – Amber colored bulbs
4 Multi Reflector type clear lens units
Meter IlluminationL.E.D
Neutral Indicator12v 3w
Turn Signal IndicatorL.E.D
Position Lamp12v 3w
12v 10w – Amber-coloured bulbs
4 Multi Reflector type clear lens units
L.E.D
License Lamp12v 5w
Fuse10 A, 15 A, 20 A

All the above data is from the owner’s manual.


Update

I rode this bike recently and here are my first impressions about the Hero Impulse.
